Precyzyjna rura stalowa

EN10305 E235 E355 Precision Seamless Steel Tube For Hydraulic Pneumatic Systems Steel Grade C Si Mn P S Al Name Number max max max max max max E215 1.0212 0.1 0.05 0.7 0.025 0.015 0.025 E235 1.0308 0.17 0.35 1.2 0.025 0.015 - E355 1.0580 0.22 0.55 1.6 0.025 0.015 - Steel Grade Yield Strength Tensile Strength Elongation Name Number Min Mpa Min Mpa % E215 1.0212 215 290-430 30 E235 1.0308 235 340-480 25 E355 1.0580 355 490-630 22 OD Allowed Tolerance Special Tolerance GB/T3639

EN 10305-1 E355 St45 St30 Low Carbon Cold Drawn Bright Annealed Seamless Precision Steel Tubes Torich has experiences of production seamless precision tube for over 20 years, can support customers with various material like E215 E235 E355 St30Si St 30Al St35 St45 St 52 STKM 11 STC38 STKM 13 STKM 19 etc.As precision seamless steel pipe has good tolerance on OD and WT,can used in Automotive application . Size range: O.D.:6-420mm W.T.:1-50mm L:max12000mm Production: Cold Drawn +

St35 St52 1026 Pre-Honed Seamless Precision Steel Tube Din 2391 Torich can produce seamless high precision steel pipe for over 20 years',are of great engineering experience in steel pipe industry for more than 20 years, which are in great command of production technology for Cold Drawing and Cold Rolling. So we have strong technician team and manufacturing capability. DIN 2391 Material Properties DIN 2391 equivalent ASTM Standard EN 10305-1, EN 10305-4, ASTM A519, NF 699,

High-pressure Boilers Seamless Steel Tube T23 T91 Omega Tube Tube and material order spection for ASME ferritic material grades. ASME material : SA192 Hot finished or cold finished seamless steel tube SA210-A1 Hot finished or cold finished seamless steel tube SA210-C Hot finished or cold finished seamless steel tube SA213-T2 Hot finished or cold finished seamless steel tube SA213-T11 Hot finished or cold finished seamless steel tube SA213-T22 Hot finished or cold finished

DIN2391 ST52 Seamless Carbon Steel Pipe For Excavator Hydraulic Pump System Torich is a manufacturer of precision carbon steel tube for over 20 years.have lots of experiences on manufacturing and exporting steel pipes. Standard as per DIN 2391 standard specifies the Seamless steel tubes used forMechanical and Automobile. Similar standard and material as below. JIS G3445 STKM 11A C STKM11A C C STKM 12A B C STKM14 A B C STKM 13 A B C STKM 15A B C STKM 16A C STKM 18 A C STKM 19A

Precision Square Steel Tube 150x150 DIN 2395 Electric Welded ST37.2 Steel Pipe 1.Brief introduction of DIN 2395 precision square steel tube: Similar standards: EN 10305-5 Material/grade: RST 37-2(E235), ST37-3(E195), St 44-2, St 44-3,USt37-2 Size dimension: Width: 10, 15, 20, 25, 30, 35, 40,50,60,70,80,etc mm; Height: 15, 20, 25, 30, 35, 40, 50, 60,70,80,100,120,150mm; WT: 1.5 - 3 mm. Length: 4M- 12M or according to customer' require. Height and width's tolerance: Height up

EN10305-1 E215 NBK Round Seamless Precision Steel Pipe for Automotive TORICH is a professional manufacturer and exporter of precision steel pipes. Cold-drawn precision seamless steel pipe is used for high dimensional precision and good surface finish of mechanical structure and hydraulic equipment. Size range: O.D.:6-420mm W.T.:1-50mm L:max12000mm Production: Cold Drawn + Cold Rolling Our regularproduction size: 60x50 42x3.2mm Size Grade O.D. W.T. L EN10305-1 5-420mm 0.5-50mm

Cold Rolled DIN17230 SAE 52100 Bearing Seamless Tube Oil PIpe Round Bar For Bearings Bearing Seamless Tube Material S1541 GCr15 G4051 SUJ2 100Cr6(1.3505) PRODUCT NAME STANDARD GRADE SIZE RANGE OD. USAGE High Carbon Anti-Friction Bearing Steel Tubes GB/T18254 GCr15 52100 SUJ2 SUJ3 100Cr6 SKF3 SKF3S 20CrNiMo 8620H 4118H 5mm to 100mm High Carbon Chromium Bearing Seamless Steel Tubes ASTM A295 Wearable High Carbon Bearing Seamless Steel Tubes ASTM A534 Wearable & Cementite

Aluminized Pipes Dx51D AS120 EN 10305-3 EN 10305-3 DX51D+Z275 or E220+CR2S4 Z275 Galvanized steel pipe Wall Thickness : 0.12~30MM Length: 500-12000MM Standard : GB/T13793-1992,GB/T14291-2006, GB/T3091-1993,GB/T3092-1993,GB3640-88 BS1387/1985, ASTM A53/A36,EN39/EN10219,API 5L,GB/T9711.1-99 etc Coating Layer Thickness : 210g-600g/m2 Application: Widely used in structure, accessorize,construction, machinery parts,fluid transportation,the stress parts of the automobile tractor
