honed hydraulic cylinder tubing
"
Precyzyjna rurka bezszwowa wyciągnięta na zimno z tolerancją ISO H8/H9 ID i Ra max 0,40 μm dla zastosowań motoryzacyjnych
Honed Hydraulic Cylinder Tubing — Precision Cold-Drawn Seamless Tube for Automotive Material Honed hydraulic cylinder tubing is a precision cold-drawn seamless steel tube whose inside diameter (ID) is honed or skived & roller burnished (SRB) to achieve tight dimensional tolerances and a very smooth bore—critical for hydraulic cylinders where sealing performance, friction, and service life depend heavily on ID quality. Typical steel families include EN precision grades (E235 /
Szlifowana rura hydrauliczna EN10305-2 z precyzyjnie spawaną rurą stalową ciągnioną na zimno
EN10305-2 DOM Hydraulic Cylinder Tube for Oil and Pnuematic Cylinders E155 E195 E235 E275 E355 EN10305-2 Welded Precision Cold Drawn Steel Tubes Honing, Skiving, Roller Burnish Applications: for Auto industry for machinery use Oil Cylinder Tube Motorcyle shock absorber Auto shock absorber innder cylinder Telescopic Cylinders Size range: ID.: 20-650mm W.T.:1-50mm L:max12000mm Steel Grade: E155, E195, E235, E275, E355. S45C Steel Grade and Chemical Compositions Steel Grade C Si
DIN2391 Szlifowane rury cylindrowe hydrauliczne ze stali bezszwowej ciągniętej na zimno
Products Description TORICH DIN2391 Cold Drawn Seamless Steel Honed Tube for Hydraulic Cylinder BK+S Standard DIN2391, EN10305, DIN17175 etc Size OD: 40-400mm WT: 5-40mm Length : Random (5-7m) or Fixed length as per order of confirmation Material ST45, ST52, E355, E355SR, STKM13C, SAE1026, 20#, Q235B, CK45, CK20, 16Mn, 27SiMn Supply Condition BK(+C), BK+S (+SR) Technology Honed & SRB (SKIVED AND ROLLER BURNISHED ) Polishing To 0.4Ra Max Tolerance Inner Diameter: ISO H8 Wall
EN10305-1 Okrągła, szlifowana rura cylindra hydraulicznego
EN10305-1 Seamless Round Hydraulic Cylinder Honed Tube Standard: EN10305-1 Steel Grade: E 235 E355 Etc Material: Carbon And Alloy Steel Grade Dimension: O.D.:6-380mm W.T.:1-35mm L:max12000mm WT Tolerance: +/-0.15mm Production Method: Seamless Cold Drawn/Rolling Delivery Condition: +Cc +LCc +SR +Ad +N NBK Applications: Hydraulic Cylinder/Oil Cylinder Tube/Excavator Chains and Parts a: Rm: tensile strength; ReH: upper yield strength; A: elongation after fracture b: 1Mpa=1N/mm2
AISI Hydraulic Cylinder Pipe / Honed Hydraulic Cylinder Tubing Średnica 46mm 38mm
TORICH Diameter 46mm 38mm AISI 1020 1010 4130 34CrMo4 DIN St35.8 St52 Seamless Carbon Hydraulic Steel Pipe Cylinder Honed Tube Manufacture Method: Cold drawn, hot rolled+deep hole bored Certification: ISO9001, SGS, Material: Carbon steel,alloy steel, stainless steel Standard&Grade: DIN2391-2 ST52,EN10305-1 E355,C45E,25CrMo4,42CrMo4, CK45,E410, E470,ASTM A519 SAE1020,SAE1026,SAE1045,SAE1518,SAE1541, SAE4130,SAE4140,SAE4145,SAE4340,etc. Size Range: ID of 300mm max for cold
Niestandardowe bezszwowe zimno rysowane grubość ścianki 30mm rury szlifowane siłownik hydrauliczny
Seamless cold drawn/rolling steel tubes Steel tubes for precision applications. Technical delivery conditions. Size range: Cylinder ID: 20-400mm O.D.:6-500mm W.T.:1-30mm L:max12000mm Steel Grade and Chemical Compositions: Steel Grade C Si Mn P S Al Steel name Steel number max max max max max min E215 1.0212 0.10 0.05 0.70 0.03 0.025 0.025 E235 1.0308 0.17 0.35 1.20 0.03 0.025 - E355 1.0580 0.22 0.55 1.60 0.03 0.025 - Mechanical properties at room temperature Steel grade
Szlifowana rura hydrauliczna precyzyjnie zgrzewana stalowa rura ciągniona na zimno EN 10305-2
Honed Hydraulic Cylinder Tube wtih Precision Welded Cold Drawn Steel Tube EN10305-2 DOM Hydraulic Cylinder Tube for Oil and Pnuematic Cylinders with steel grade E155 E195 E235 E275 E355 EN10305-2 Welded Precision Cold Drawn Steel Tubes Honing, Skiving, Roller Burnish Applications: for Auto industry for machinery use Oil Cylinder Tube Motorcyle shock absorber Auto shock absorber innder cylinder Telescopic Cylinders Size range: ID.: 20-650mm W.T.:1-50mm L:max12000mm Steel Grade
TORCIH GB 18248 37Mn 30CrMo Bezszwowa hydrauliczna rura cylindra do butli gazowej
TORCIH GB 18248 37Mn 30CrMo Seamless Hydraulic Cylinder Tube for Gas Cylinder SPEC: Material:37Mn 30CrMo 34CrMo4 35CrMo Diameter : 4-1200mm Wall thickness : 0.3-200mm Length : 4-6m Upon customer's request Production method: Hot rolling(extrusion), cold drawn, cold rolled Delivery condition: BK,GBK,NBK Chemical composition of Seamless Steel Tube for GasCylinder: Steel Grade Chemical composition C Si Mn P S P+S Cr Mo V Ni Cu 37Mn 0.34-0.40 0.10-0.30 1.35-1.65 ≤0.030 ≤0.030 ≤0
Rura do siłowników hydraulicznych ciągniona na zimno ASTM A519 40-400mm ID
ASTM A519 DOM Tube For Hydraulic Cylinder And Pneumatic Cylinder Standard : GB/T3639, GB/T8713, EN10305-1:2002, EN10305-2:2002, ASTM A519-2006, ASTM A513-2007, GB/T1591-2008, GB/T17396-2009 Material: 20#, 45#, Q345B, Q345D, 25Mn, 27SiMn, E355 Hydraulic and pneumatic cylnder tube standard/size/tolerance Working method Tube ID (mm) Length (m) Straightness (mm/m) Tolerance on ID Tolerance on WT ID Roughness (um) Cold Draw 40-400 ≤12m 0.2-0.5 / ±5% ≤1.6 Cold Rolled 40-150 ≤12m 0
